Iowa’s Kinnick Stadium gets new DAS for 2017

October 5, 2017 by Leave a Comment

DAS antennas seen on flagpoles at Iowa’s Kinnick Stadium. Credit: Gary Turner / CWS (click on any photo for a larger image)

Fans at the University of Iowa’s Kinnick Stadium should finally have cellular connectivity this season, thanks to a new neutral-host DAS installed by Connectivity Wireless Solutions over the past offseason.

Though we don’t have any stats or speed test reports yet, Connectivity Wireless said the DAS was scheduled to begin operation at the start of the season, with fine-tuning taking place during the first few home games. Verizon Wireless and U.S. Cellular were active on the DAS at the start, according to Connectivity Wireless, with AT&T in testing at the season’s start.

Steven Morris, director of engineering for Connectivity Wireless, said the new DAS is using Corning One gear at the core, and has a mainly fiber infrastructure with coax used only in the “final 30 to 40 feet” for connection to edge gear and antennas. Connectivity Wireless also installed a new DAS at the school’s basketball stadium, Carver-Hawkeye Arena, which should also be ready for the upcoming season. According to news reports, the DAS contract for Kinnick is $6 million, while the cost for the network at Carver-Hawkeye is $3 million.

The DAS for the 70,000-seat historic Kinnick Stadium, Morris said, has 13 sectors, and according to news reports, uses approximately 200 antennas. Like many older open-bowl stadiums, deployment at Kinnick was a challenge simply due to its design as well as to the fact the building has historical aesthetic elements, making antenna placement a job with multiple approvals necessary.

Overhead view of the bowl shape of Kinnick Stadium. Credit: University of Iowa

Overcoming aesthetic and design challenges

“There was no real place for antennas,” said Morris, who said Connectivity Wireless found a way to bring coverage to the main bowl seating partially through a strategy of replacing existing flagpoles mounted around the stadium’s edges with new custom-designed poles that had conduit and antenna mounts built in.

“It was a big challenge for us, with lots of approvals to go through,” said Morris. Connectivity Wireless also had to trench fiber from the stadium to the campus’ network head-end, which is located in one of the school’s hospitals about a mile away from Kinnick. All this work needed to be done in the spring and summer, Morris said, since you can’t dig underground in Iowa where winter weather can regularly produce sub-zero temperatures.

With plenty of fiber capacity now in place, Morris said Kinnick Stadium could also eventually install a Wi-Fi network, though it would most likely mean some kind of under-seat AP deployment with its associated coring costs. However, there still may be some legal entanglements regarding any future network deployments, as Iowa is still involved in a lawsuit with American Tower, which it had originally contracted with to build the Kinnick DAS. That 2013 deal, however, was terminated by the university in 2015, and the matter is still being adjucated under a lawsuit filed by American Tower. American Tower would not comment on the status of the lawsuit.

More flagpole-mounted DAS at Kinnick Stadium; Credit both photos: Gary Turner / CWS

Filed Under: 4G LTE, AT&T, DAS, NCAA Football, Verizon Wireless Tagged With: , , , , , , , , , , ,

New Colorado State stadium has winning Wi-Fi network

October 3, 2017 by Leave a Comment

Colorado State University has a new on-campus football stadium. Credit all photos: Paul Kapustka, MSR (click on any photo for a larger image)

Even though it’s not completely finished, the Wi-Fi network at Colorado State University’s new football stadium has already shown strong signs of promise, signaling a future with great connectivity for Rams fans at their new on-campus venue.

Being built by integrator 5 Bars, the network is in its final phases of completion, with enough of it turned on to get some positive results in the first two home games for Colorado State this season.

On Aug. 26, during Colorado State’s 58-27 win over visiting Oregon State, a sellout crowd of 37,583 crammed into the new on-campus venue for the Fort Collins, Colo., school. During the inaugural event, the not-yet-finished Wi-Fi network nevertheless saw 5,891 unique connections during the day with a peak concurrent number of 3,680 users at 3 p.m. local time, according to 5 Bars. Even with most of the under-seat Wi-Fi connections not yet online (5 Bars said the network was about at 35 percent capacity), the network still saw 2.7 terabytes of data used, an average of 458 MB per connected user.

Some under-seat Wi-Fi APs needed conduit cored through the concrete steps

A couple weeks later, Mobile Sports Report was in the house for CSU’s second home game, a 38-10 victory over Abilene Christian. With 27,038 fans in attendance, many wearing bright orange to celebrate CSU’s “Ag Day” heritage (the official school colors are green and gold), the network saw 4,548 unique users and 1.8 TB of traffic, according to 5 Bars.

Under-seat coverage impressive

Editor’s note: This profile is an excerpt from our latest STADIUM TECH REPORT, our Fall 2017 issue that has in-depth profiles of network deployments at Notre Dame Stadium, Mercedes-Benz Stadium, and the Los Angeles Coliseum. DOWNLOAD YOUR FREE COPY of the report today!

If there is a design tactic that seems to have paid off, it’s 5 Bars decision to go under-seat with Wi-Fi APs in most of the lower seating bowl. With 250 in-bowl APs out of the estimated 419 total APs used in the venue, many are in under-seat enclosures, both in premium areas with seats with backs, as well as in seating areas with metal benches.

And while building a stadium from scratch with Wi-Fi in mind usually means under-seat deployment can be easier, 5 Bars found that in the end it needed to place some APs in different spots, leading to some on-site construction that included coring holes in concrete steps to thread conduit across some aisles. The end result, however, is impressive, with MSR speed tests hitting the mid-50 Mbps and into the 60-Mbps marks for both download and upload speeds in most of the lower bowl seating, with tests taken before the game in an empty stadium.

The on-campus proximity of the new stadium is a welcome change for CSU fans

But even later, with orange-clad CSU fans filling the seats, the working Wi-Fi network still performed admirably, with a 63.58 down and 48.35 up reading in the middle of the student section on the stadium’s east side during the first quarter. Closer to the end of the first quarter, we got a 24.33 / 9.96 reading in the lower section of the west side, the most tightly packed area in the stadium that day.

Light standards and beer gardens

While under-seat placements may be the workhorses at CSU’s new stadium, there are also plenty of overhead APs to fill in the gaps, such as at the top of the lower-bowl sections, mounted underneath the overhang. There are also Wi-Fi APs as well as DAS antennas on the large light standards that top the east stands. Though we didn’t test the DAS network, 5 Bars has a neutral host deployment that currently has Verizon Wireless online, with AT&T and T-Mobile to follow soon. Sprint is scheduled to be added next year, with support for Sprint’s 2.5 GHz spectrum, 5 Bars said.

One thing that makes the new CSU stadium unique is the New Belgium Brewing beer garden that fills the north end zone of the stadium. With several rows of long, stand-up tabletops where fans can sip a beer while watching the game, as well as a bar area behind, the beer garden was already a popular place to hang out, as evidenced by the big line that formed shortly after the stadium opened.

And thanks to the structures over the bar area, the beer garden was well covered by Wi-Fi APs mounted above the taps. Even down in one of the stand-up rows close to the field we were still able to get a Wi-Fi reading of 55.69 down and 24.11 up. We also taste-tested New Belgium’s “Old Aggie Lager,” a brew made specifically by the local company for CSU. It’s crisp and refreshing, especially on a sunny Saturday afternoon. And it goes perfectly with good Wi-Fi.

Fans are able to share social media posts via the new big screen video board

A look at the west stands from the back of the student section

An overhead look at the north end zone beer garden, with a view to the mountains just west of the venue

The beer garden standing area provides an up-close look at the action

As always, Mobile Sports Report tests, tests and tests again

Filed Under: 4G LTE, Cisco, DAS, NCAA Football, Wi-Fi Tagged With: , , , , , , , , ,

MSR at MWC: Come see us in San Francisco!

September 13, 2017 by Leave a Comment

If you are attending the Mobile World Congress Americas show this week in San Francisco, make sure you check out the Thursday morning series of keynote presentations moderated by yours truly, including a “fireside chat” with Al Guido, president of the San Francsico 49ers. Al and I will talk about Levi’s Stadium and how the Niners are using their digital strategy to better engage fans… be sure to start your Thursday morning with us! We get underway at 9 a.m. local time, so hit the Starbucks and come on by.

In addition to Al, there are four other keynote presenters who all represent a different part of the customer engagement equation. And later Thursday morning, you can continue your stadium-tech experience by checking out the panel discussion on The Connected Stadium: Enhancing Fan Engagement with representatives from the Utah Jazz, Sacramento Kings, Atlanta Hawks and Soldier Field (home of da Chicago Bears), as well as FC Barcelona. Moderated by Brian Berger, host of the excellent Sports Business Radio podcast, the panel starts at 11 a.m. local time.

Filed Under: 4G LTE, DAS, Wi-Fi Tagged With: , , , , , ,

Denver Broncos, Verizon bring Wi-Fi blitz to Sports Authority Field at Mile High

September 5, 2017 by Leave a Comment

Railing-mounted Wi-Fi enclosures in the lower seating bowl at Sports Authority Field at Mile High in Denver. Credit all photos: Paul Kapustka, MSR (click on any photo for a larger image)

Even as the team on the field seeks to regain its recent Super Bowl champion status, Denver Broncos fans will have something they can all cheer this season — vastly improved Wi-Fi networking service, which is now available to all fans and not just Verizon Wireless customers.

Even though we found good connectivity on our last visit to Sports Authority Field at Mile High two seasons ago, the caveat was that Wi-Fi was only available to Verizon customers, since the carrier couldn’t find another wireless provider who would chip in to fund the system. Fast-forward to later in 2016, when Verizon and the Broncos sought to upgrade the entire system and ended up picking a $6 million bid from Cisco to install a total of 1,470 new Wi-Fi APs, replacing the 640 APs in the old system, which started out with 500 Cisco APs in 2011 and added some more over the years.

The new network, which is scheduled to be fully completed by late October or early November this year, is already live in parts of the lower bowl at Mile High as well as in many concourse, suite and back-of-house locations. The big difference inside the hardware is the Broncos’ and Verizon’s choice of using the new Cisco 3800 APs, which can have two separate antennas in each device, basically doubling the amount of connectivity per unit. The new network will be powered by a new 10-gig backbone pipe provided by CenturyLink, replacing the 1-Gbps pipe that was previously used.

Close-up of a lower-bowl railing AP mount.

Cisco 3800s are proving to be a popular choice in venues lately, being picked for recent deployments at the San Jose Sharks’ SAP Center and at Notre Dame Stadium.

“The 3800 is a game-changer,” said Russ Trainor, the Broncos’ vice president of information technology, during a stadium tour Tuesday, citing its ability to connect more fans per device. Perhaps the most visually striking note of the upgrade is the huge amount of new railing-mounted APs in the building, with several per row not an uncommon sight in the lower bowl. Jason Moore, a senior IT engineer with the Broncos (and as Trainor calls him, a “Wi-Fi wizard”) said the enclosures are all custom designs from a local provider, with some of the fiberglass structures housing not just Wi-Fi but Verizon DAS antennas as well.

(Right now, the DAS situation at Mile High remains unchanged from our last visit, with all cellular carriers basically running their own operations.)

Going under-seat in bright orange fashion

The other new deployment method being used by the Broncos is under-seat placement, a tactic used for about 90 APs so far, half of those in the South end zone seats, where there are no overhead structures at all. Overhead AP placements are also being used in the main seating bowl, mainly to serve rows at the tops of sections.

No mistaking where the under-seat APs are at Broncos games.

Unlike other stadiums, who try to hide the under-seat APs as best they can, the Broncos have gone the opposite direction, painting many a bright Broncos orange to show up under the Broncos blue seats. “The mounting options are just about getting the APs as close to fans as we can,” Moore said. “Railing [mounts] work great. Under seat is new to us, and we’re excited to see how they work.”

In a quick empty-stadium test, MSR found Wi-Fi speeds in the south stands of 46 Mbps download and 47 Mbps up, on both the all-access and Verizon-customer SSIDs. In section 309, right at the 50-yard line, we got a Wi-Fi speed reading of 69 Mbps down, 75 Mbps up. Verizon execs at the tour said that like at other NFL stadiums where Verizon helps provide the Wi-Fi, Verizon customers will have reserved bandwidth and an autoconnect feature that links them to Wi-Fi without any sign-in needed. Trainor said the Broncos are still undecided how to approach the all-access Wi-Fi onboarding, though the team is leaning in the favor of having some kind of portal approach to gather information from fans using the service.

Of the 1,470 planned new APs (that count may change as final tuning is made, Moore said), the Broncos plan to deploy 920 of those in the seating bowl. With many of those devices having two 5 GHz antennas for each AP, the Sports Authority Field at Mile High crowds should enjoy one of the league’s top network experiences when all the work is completed.

Both railing and under-seat deployments are used to bring Wi-Fi to the south stands.

Those readers who closely track MSR stories for such stats should know that we are now working on a new chart to show not just the top numbers of APs in stadiums, but actual radios and antennas thanks to devices like the Cisco 3800 that have more than one per unit. (Any and all help with such counts is appreciated, you know where to find us!)

Like other stadiums, the network in the bowl at Sports Authority Field at Mile High will switch to only 5 GHz connections when complete. Even a few years ago, stadiums needed to still support 2.4 GHz Wi-Fi connections for fans, but the quick shift in consumer devices has shown that almost all mobile devices used these days have a 5 GHz radio.

A string of summer concerts at the stadium (which still bears the name of the now-bankupt and closed sporting-goods business as the Broncos search for a new title sponsor) kept the network deployment from being completed sooner, but Trainor and Moore said the incremental improvements are already being noticed. With both the old system and new system working simultaneously, Moore said that at last week’s college game between the University of Colorado and Colorado State University, the network saw approximately 35,000 unique users — more than the typical 25,000 unique connections during a Broncos game when only Verizon customers could use the network.

“Our goal and challenge is to connect as many fans as possible,” Moore said.

A smaller railing mount seen in the upper deck (300 level) seating section

Wi-Fi antenna mounts in the ceiling of the United Club

Wi-Fi coverage also exists for the fan-gathering area outside the stadium to the south

No Wi-Fi here, just white horses

Filed Under: 4G LTE, Cisco, DAS, Denver Broncos, Denver Broncos, NFL, Super Bowl, Verizon Wireless, Wi-Fi Tagged With: , , , , , , , , , , , , ,

Long-promised Mobilitie DAS goes live at San Jose Earthquakes’ Avaya Stadium

September 1, 2017 by Leave a Comment

Just before game time at Avaya Stadium for the 2016 MLS All Star game. Credit all photos: Paul Kapustka, MSR

The San Jose Earthquakes’ Avaya Stadium, which opened more than two years ago, finally has a working DAS, according to a press release from DAS provider Mobilitie.

Mobilitie, which won the deal back in 2015, said its neutral-host deployment has more than 150 antennas. The release did not say which carriers have agreed to deals or are live on the system; we are awaiting a response to an email to Mobilitie and Avaya folks, so stay tuned.

Since its opening, Avaya Stadium has had Wi-Fi provided by the namesake sponsor, a network that got considerably better ahead of last summer’s MLS All-Star Game. Any Quakes fans who can take some cell-service speedtests, send them our way.

Filed Under: 4G LTE, DAS, MLS Tagged With: , , , , , , , ,

Alamodome taps AmpThink for new Wi-Fi ahead of 2018 Final Four

August 30, 2017 by Leave a Comment

A new full-stadium Wi-Fi network installed by AmpThink is coming to the Alamodome, scheduled to be finished just ahead of this year’s Alamo Bowl and well in place for next spring’s men’s NCAA basketball tournament’s Final Four, Alamodome executives said.

Scheduled to be announced publicly by the San Antonio, Texas, venue today, the new network is part of a $50-million-plus renovation project that includes updated video boards, sound systems and TV screens throughout the stadium. Nicholas Langella, general manager of the Alamodome, said the new Wi-Fi network was financed in part by donations from Alamodome customers, including the Valero Alamo Bowl, scheduled this year for Dec. 28. The network will use Wi-Fi gear from Cisco, according to Langella.

According to Langella, approximately $6 million out of the roughly $10 million needed for the Wi-Fi upgrade came from the Alamo Bowl. Langella also said that the venue now has an updated DAS as well, built by Verizon, which will also have AT&T and T-Mobile on board. “We’re very happy about that [the DAS],” said Langella in a phone interview.

Going under seat for Wi-Fi

Though Wi-Fi deployment firm AmpThink has lately preferred railing Wi-Fi enclosures for proximate network builds, such as at Notre Dame, Langella said the Alamodome deployment will use more under-seat AP placements than railings, given the designed mobility of the Alamodome seating areas. “We have so much mobility with the stands, it’s hard to do lots of railing [placements],” Langella said.

According to Langella when the Wi-Fi deployment is finished — the network is scheduled to be fully completed by Dec. 1 — there will be approximately 750 APs installed, allowing the Alamodome to increase coverage from being able to serve 3,500 fans to being able to cover 65,000 fans, meaning every seat in the house. The improvements, he said, were part of a plan to attract the Final Four, which succeeded.

“We always thought we would improve the Wi-Fi,” Langella said. With the Final Four looming, he said, “we took the bull by the horns and got it done.”

Filed Under: 4G LTE, AmpThink, AT&T, Basketball, Cisco, DAS, NCAA Hoops, T-Mobile, Verizon Wireless, Wi-Fi Tagged With: , , , , , , , , , , , , , ,
